TECHNICAL SPECIFICATIONS (cont.)
• Specifications are subject to change without notice.
Note:
*1: With two 20 feet (6.1 m) ducts containing one 90° bend each, supply grill and
return grill with filter [0.30 IWG (75 Pa)] external static pressure] on high fan
speed.
*2: Confirm pressure drop of duct, grills, and filter with manufacture’s
specifications.
*3: Measured at 3 feet (1.0 m) under the ceiling with evaporator duct and ceiling
tile.
Item Specifications
Dimension W × D × H Without
Flange
45.4 × 31.5 × 20.0 in
(1,154 × 800 × 511 mm)
With Flange 49.4 × 35.4 × 20.0 in
(1,254 × 900 × 511 mm)
Weight Net 236 lb (107 kg)
Condensate Pump
Capacity
Pump Rate 5.0 gal/h (19 L/h)
Head 4 ft (1.2 m)
Operating Condition
Range
Inlet Air
Temperature
Max. 95 °F (35 °C), 50 %RH
Min. 55 °F (12 °C), 50 %RH
Entering
Water
Temperature
Max. 115 °F (46 °C)
Min. 45 °F (7 °C)
Water Pressure 150 psi (1,034 kPa) or less
Recommended Water Flow
Rate
7.1 gal/min (27 L/min)
Maximum Duct
Length
*2
Cold Duct
120 ft (36.6 m)
Maximum Sound Level
*3 55 dB (A)
