Smithco Spray Star 1000 (sn 100199 – 100223) Parts & Service Manual - Manual (Page 29)

Par
ts
27
FOOT PEDAL LINKAGE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 10-323 Seat Panel 1
10-326 Decal, Control Panel 1
42-116 Rubber Insert 6
2 48-066 Pedal Pad 1
3 10-163 Forward Foot Pedal 1
HMB-12-14 Machine Bushing 1 /
2
x 14GA 2
HP-18-075 Cotter Pin 1 /
8
x 3 /
4
1
4 76-296 Pedal Mount 2
18-234 Bushing 4
HG-14-28-180 Grease Fitting 1 /
4
- 28 x 180° 2
5 48-132 Short Pedal Pad 1
6 10-164 Reverse Foot Pedal 1
HMB-12-14 Machine Bushing 1 /
2
x 14GA 2
HP-18-075 Cotter Pin 1 /
8
x 3 /
4
1
7 21-462 Ball Joint 2
HN-516-24 Nut 5 /
16
- 24 2
8 10-148 Reverse Linkage 1
HN-516-24 Nut 5 /
16
- 24 1
HP-18-075 Cotter Pin 1 /
8
x 3 /
4
1
9 10-178 Relay 1
18-234 Bushing 2
HG-14-28-180 Grease Fitting 1 /
4
- 28 x 180° 1
HMB-12-14 Machine Bushing 1 /
2
x 14GA 2
HP-18-075 Cotter Pin 1 /
8
x 3 /
4
1
10 18-115 Ball Joint 1 /
4
NF 2
HWL-14 Lock Washer 1 /
4
2
HN-14-28 Nut 1 /
4
- 28 4
11 10-149 Forward Linkage 1
HN-516-24 Nut 5 /
16
- 24 1
HP-18-075 Cotter Pin 1 /
8
x 3 /
4
1
12 HST-516-18-075 Truss Head Machine Screw 5 /
16
-18 x 3 /
4
4
HNTL-516-18 Lock Nut 5 /
16
-18 4
13 42-063 Cable with Nuts 1
14 HB-516-18-400 Bolt 5 /
16
-18 x 4 2
HNTL-516-18 Lock Nut 5 /
16
-18 2
15 10-228 Spray Boss Control 1
10-134 Spacer 2
16 10-190 Cable, Spray Boss Control 1
17 10-166 Rear Engine Mount 1
18 11-100 Yoke 5 /
16
2
HN-516-24 Nut 5 /
16
-24 2
HCP-516-100 Clevis Pin 5 /
16
x 1 2
HP-18-100 Cotter Pin 1 /
8
x 1 2
19 10-151 Swash Plate 1
20 10-137 Main Frame 1
21 10-189 Speed Boss 1
18-289 Bushing 2
22 10-206 Hood Rod Bracket 1
23 33-216 Battery (Optional) 1
(Continued on next page)
