65
Accessories
CONTROL 1002 SYSTEM PARTS LIST
(RAVEN 203)
REF# PART# DESCRIPTION QUANTITY
1 10-259 Mounting Bracket 1
2 16-898 Boom Switch 3
3 16-900 Mounting Knob 2
4 16-899 Master Switch 1
5* 16-958 Console (only) 1
6 33-090-02 Liquid Filled Pressure Gauge 1
7 16-958-02 Fuse Holder 1
16-525-03 Fuse 15 AMP 1
8 16-895 Pressure Switch 1
9* 16-958-04 Cable Assembly 8ft Enclosure Hook-Up 1
10* 16-958-05 Union Fitting 1
11* 16-866 Motorized Control Valve 1
12 15-552 Manifold Ball Valve 1
13 16-183 Tee FPT 1 x 1 x 1 1
14* 16-955 Tubing 1
15* 16-902 Cable Assembly 72" Solenoid Hook-Up 1
16 33-271 Fuse Block 1
17 33-284 Auto Blade Type Fuse 5 amp 1
18 10-225 Wire Harness (fuse block to electric valve) 1
19 33-508 Auto Blade Type Fuse 15 Amp 1
* 16-852 203 Sprayer Control Kit (includes all * items)
Use Dielectric Grease On All Electrical Connections
16-456 FLOW METER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 16-456-03 O-Ring Viton 2
2* 16-456-04 RFM55 dual O-Ring XDCR assembly 1
3 16-456-05 RFM55 turbine 1
4 16-456-06 Turbine hub/bearing assembly 1
5 16-143 Turbine stud assembly 1
6 16-456-01 Sensor housing 1
7 16-456-02 #10-32 x 3 /
4
stainless steel screw 12
8 16-144 O-Ring Viton 1
9 16-456-07 Hub housing with inserts 1
16-456-08 Mounting bracket RFM 55 1
16-456-09 Thread sealer 1
* 16-456-10 O-Ring Transducer Kit
