Version 2.4 Page 8 of 55 SMT390-VP User Manual
Physical Properties
Dimensions Width: 63.5mm.
Length: 106.68mm.
Height: 21mm maximum.
Weight 104 Grams (including fan and fixings)
Supply Voltages
3.3V and 5V
Supply Voltages available on Daughter
Module 1.5V, 2.5V, 3.3V, 5V, +12V and –12V
Supply Current +12V
+5V
+3.3V
-5V
-12V
MTBF 31398.75 hours
Temperatures (measured in a 23-
degree environment)
FPGA – SMT338-VP 67°C max
ADCs – back SMT390 52°C max
SMT390 board 45°C max
SMT338-VP board 61°C max
FPGA Usage
RAMB16 8 out of 136 (5%)
Slices 3909 out of 13696 (28%)
Bufgmux 9 out of 16 (56%)
DCMs 4 out of 8 (50%)
