6.3. SHB
For the relationship between FPGA pins and connectors, please refer to: SUNDANCE SHB
specification
6.4. SLB
For the relationship between FPGA pins and the connector, please refer to: SUNDANCE
SLB specification
6.5. JTAG
Figure 7: JTAG connector Top View
