8 – Specifications

TASCAM US-1641
Inputs and outputs
MIC IN [1-8] jacks (analog)
Connector XLR-3-31
Type and wiring Balanced (1: ground, 2: hot, 3: cold)
Input impedance 2.2k Ω
Input level (with the Gain knobs set at maximum) –58dBu
Input level (with the Gain knobs set at minimum) –2dBu
Headroom 16dB
LINE IN/GUITAR [9-10] jacks (analog)
Connector 1/4” phone jack
[With the LINE IN-GUITAR switch set to LINE IN]
Type and wiring Balanced (Tip: hot, Ring: cold, Sleeve: ground)
Input impedance 10k Ω
Nominal input level (with the Gain knobs set at maximum) –42dBu
Nominal input level (with the Gain knobs set at minimum) +4dBu
Headroom 16dB
[With the LINE IN-GUITAR switch set to GUITAR]
Type Unbalanced
Input impedance 700k Ω
Nominal input level (with the Gain knobs set at maximum) –52dBv
Nominal input level (with the Gain knobs set at minimum) –6dBv
Headroom 6dB
INPUTS [11-14] jacks (analog)
Connector 1/4” phone jack
Type and wiring Balanced (Tip: hot, Ring: cold, Sleeve: ground)
Input impedance 10k Ω
Nominal input level (selectable with the LEVEL switch) +4dBu or –10dBv
Headroom 16dB
DIGITAL IN jack (digital)
Connector RCA pin jack
Signal format IEC958 Consumer (S/PDIF)
Level 0.5Vpp/75 Ω
