Thinklogical Velocityrgb System-9, 10 and 12 Manual - Manual (Page 10)

Revision D 5 December 2012
2.3 Technical Specifications
Storage Temperature -20 to 70 o C (-4 to 158 o F), 10 to 90% RH, non-condensing
Power Consumption Transmitter: <15 Watts, typical
Receiver: <15 Watts, typical
Front Panel Display Transmitter and Receiver: 2 x 24 Liquid Crystal Display
Copper Cables
(Supplied with system)
Velocity 9 TX
Qty 1 CBL000020-002MR HD15 (M) to HD15 (M) Cable, 2M
Velocity 10 TX
Qty 1 CBL000013-002MR DVI(M) to DVI(M) Cable, 2M
Velocity 12 TX
Qty 1 CBL000020-002MR HD15 (M) to HD15 (M) Cable, 2M
Qty 2 CBL000041 6FT VGA/HD15 to 3-RCA COMPONENT
Optical Cable Single Mode or Multi Mode, depending upon model
Optical Distance Up to 65 meters with Type OM1
Up to 350 meters with Type OM2
Up to 650 meters with Type OM3
Up to 1000 meters with Type OM4
Dimensions Velocity 9
Height: 1.19” (3.016cm)
Depth: 10” (25.4cm)
Width: 6.49” (16.5cm) Weight: <1lb (0.45kg) Each
Shipping Weight: 4lbs (1.81kg) Pair
Velocity 10
Height: 1.19” (3.016cm)
Depth: 10” (25.4cm)
Width: 6.49” (16.5cm) Weight: <1lb (0.45kg) Each
Shipping Weight: 4lbs (1.81kg) Pair
Velocity 12
Height: 1.19 inches (3.016 cm)
Depth: 10 inches (25.4 cm)
Width: 6.49 inches (16.5 cm)
Weight: <1 lb (0.45 kg) each
Shipping Weight: 4 lbs (1.81 kg) (one Velocityrgb System-12
transmitter and one Velocity receiver)
(Tolerance: ± .039"; .1000 mm)
Operating Temp
and Humidity
0° to 50°C (32° to 122 °F), 5% to 95% RH, non-conde nsing
Supply Voltage AC/DC Adapter Universal Input 90-264 VAC
Compliance Approvals for US, Canada, and European Union (pending)
Warranty
12 months from date of shipment. Extended warranties
available.
