XCRON and XCROFF
Enables or disables sending CR's on each line. XCRON is typically used when a (Windows) telnet client connecting to
the VxRouter requires each line to end with a CR/LF pair.
Format:
XCRON
or
XCROFF
Example Results:
R0003OK
XMAXCARDS
Returns the maximum number of either upstream or downstream cards in the switch. The total number of cards in the
system is twice the value returned. The Vx160 has 8 upstream and 8 downstream cards for a total of 16 cards. To
maintain consistency, the VxRouters that are uni-directional (the Vx80 and Vx320-Video) also return half the number of
cards.
•
The Mx family of Routers are uni-directional. However, the Mx48 only has 3 I/O cards, so it is not possible to return
½ the number of cards. So, the Mx family will return the maximum number of cards.
Bit 3 of XOPTIONS may be used to determine if XMAXCARDS returns ½ the number of cards (default) or the actual
number of cards (i.e. for the Mx family).
UpStream Cards
DownStream Cards
Total cards
Returned value
XOPTIONS bit 3
Vx40
8
8
16
8
0
Vx80
16
0
16
8
0
Vx160
8
8
16
8
0
Vx320
20
20
40
20
0
Vx320-Video
20
0
20
10
0
Hx80
16
0
16
8
0
Hx576
36
0
36
18
0
Mx48
3
0
3
3
1
Vx640
32
0
32
16
0
Table 2: XMAXCARDS return values
The Vx160 example shows the message returned when the 'verbose' API command line option is enabled. In this case,
the API command is returned at the end of the response message.
Format:
XMAXCARDS
Example Results:
(Vx40)
R0007OK0008
(Vx160) R0017OK0008#XMAXCARDS
(Vx320) R0007OK0020
XQUIT
Ends the network connection.
Jun 12, 2014
Router ASCII API: V4.5-1
11/33
