MAN-000019
8
REVISION A
3.2.
Rear Panel View
3.2.1.
Converter Version
– AIC-000001
DVI-D Connector (Panel)
+5VDC
CNTRL
UPDATE
DVI-D Connector (Panel)
VGA IN
VGA OUT
DVI OUT 1
DVI OUT 2
3.3.
Cables
3.3.1.
DVI-D Male to Male Cable, 2 meters
– Qty 2
3.3.2.
HD15 Male to Male Cable, 2 meters
– Qty 1
DVI-D Connector (Cable)
DVI-D Connector (Cable)
HD15 Male
HD15 Male
