MAINTENANCE
32
10. Power out the hose (A) from the pump chamber
by jogging the drive motor.
7.6.2 Cleaning the pump head
1. Isolate the pump from the electrical supply.
2. Use lifting hole (D) to move the cover. Remove
the cover (B) by loosening the retaining bolts
(A).
3. Check the sealing ring (C) and replace it if
necessary.
4. Rinse the pump head with clean water and
remove all residues. Make sure that no rinsing
water remains in the pump head.
WARNING
During jogging the drive:
-
Do not stand in front of the pump
ports.
- Do not try to guide the hose by
hand.
WARNING
Never dismount the cover, when the pump
hose is in the pump head. The compres-
sion forces on the pump hose are partially
compensated by the cover. By removing
the cover, the pump housing may become
deformed.
