SPECIFICATIONS
58
10.1.3 Surface treatment
•
After surface preparation, one layer of two-component acrylate is used for
surface protection. Standard colour is RAL 3011, however other colours are
optional. Contact your Bredel representative for details on surface treatment.
•
All galvanised parts have been provided with an electrolytic zinc layer of 15 - 20
microns.
10.1.4 Lubricant table pump
10.1.5 Weights
Bredel
40
Bredel
50
Bredel
65
Bredel
80
Bredel
100
Lubricant
Bredel
*
*
Bredel Genuine Hose Lubricant is registered at NSF: NSF Registration No 123204; Cate-
gory Code H1. See also: www.NSF.org/USDA.
Bredel
*
Bredel
*
Bredel
*
Bredel
*
Required quantity [litres]
5
10
20
40
60
Should you require additional information with respect to the safety data
sheet, consult your Bredel representative.
Description
Weight [kg]
Bredel
40
Bredel
50
Bredel
65
Bredel
80
Bredel
100
Hose pump, maximum weight
*
*
Maximum net weight of the hose pump with the heaviest gearbox and electric motor.
180
325
558
930
1300
Pump head
**
**
Weight of a completely mounted pump head (inclusive of hose, lubricant and supports).
121
227
398
672
1032
Rotor
14
24
40
77
118
Pressing shoe
0.8
1.8
4
6.6
12.6
Pump cover
16
30
62.5
106.5
195
Drive shaft
2.5
5.9
7.7
16.6
19.5
Hub
10
16
18
38
53
Hose
3.8
6.4
11.5
21
31
