INSTRUCTION HANDBOOK
FF30 V2
FF30 IH EN 74-216-201 v1.20.doc Page 16 of 26
4.3 Adjusting the height of capping head
Adjusting the height of the capping head must be repeated until the cap is tightened satisfactorily.
A correct capping function is depending on the placement of the capping unit, and the type of cap and
bottle.
Place a bottle with a cap underneath the capping
unit. The cap must be tightened into end position.
Press ADJUST, to lower the capping unit.
Loosen the finger screw on the capping unit and
lower it until the capping head is resting on the
top of the screw cap. Fasten the finger screw.
Now press ADJUST again, and the capping head
will return to top position.
Loosen the finger screw once more, and lower
the capping unit app. 5-10 mm before tightening
the finger screw again.
4.4 Adjusting the capping torque
Pull the black clutch casing
sleeve down.
Turn the capping head until the
adjustment lock plate is visible
through the slot. Insert a screwdriver and adjust
torque by turning.
Increase = clockwise
Decrease = counter clockwise
