User’s manual – X-Treme Audio MISI User Manual
Page 18
8
XTMISI
Middle-Sized Line Array module - Power handling RMS: 900 W - Impedance (bi-amp) 8+8 Ohm - Max SPL: 136 dB
4
XTMISIS
Arrayable double subwoofer - Power handling RMS: 2400 W - Impedance: 4 Ohm - Max SPL: 140 dB
2
XTDT4800F
Stereo Switching Class D Amplifier with PFC (95-265 VAC) - Output Power RMS: 4x1200 W (@4 Ohm)
1
XTDT6000F
Stereo Switching Class D Amplifier with PFC (95-265 VAC) - Output Power RMS: 4x1500 W (@4 Ohm)
1
XTDP26
Digital Speaker Management System - Ways: 2 Input, 6 Output - Frequency response: 12÷20k Hz ±0.5 dB
UNITS
= Utilized loudspeaker systems-power amplifiers connections.
1+
1-
2+
2-
3+
3-
4+
4-
NL8
LF+
(XTMISI)
LF-
(XTMISI)
Mid/Hi+
(XTMISI
bi-amp)
Mid/Hi-
(XTMISI
bi-amp)
High+
(XTMISI
tri-amp)
High-
(XTMISI
tri-amp)
NL8
SW+
(XTMISIS)
SW-
(XTMISIS)
Pins
Type
DSP UNIT
SOUND FILE
OUTPUT
OPTIONS
FUNCTION
XTDP26
4_XTMISI_BiAmp_Stereo.dfa
Near/Far*
Array made of 4 bi-amplified elements
without subwoofer
4_XTMISI_BiAmp+XTMISIS_Stereo.dfa
---
Array made of 4 bi-amplified elements
with subwoofer
(*) The “Far” output has a boost in the ultra- high frequency zone; to be used for a set of upper modules which are positioned in the top part of the array (suspended or stacked), depending on installation
geometry and environmental conditions (architecture, humidity), to throw the very high frequencies far enough, despite air absorption.
The XTMISI and XTMISIS cabinets are fitted with a pair of Neutrik
Speakon NL8 connectors. The double Speakon connector per-
mits the parallel connecton of a further loudspeaker system of the
same type. All eight pins of both connectors are wired in parallel.
The XTMISI uses pin assignments 2+/2- for woofer, 3+/3- for
mid-high section in bi-amp (this configuration) and 4+/4- for
high section in tri-amp. Pins 1+/1- are designed for XTMISIS
subwoofers.
CONNECTORS
PROCESSOR PROGRAMS
ACCESSORIES
STD-MISI
Flying bar for Middle-Sized Line Array
XT-ANGLE
Electro-mechanical device for setting the pitch of the line array systems (flying bar not included)
XT-ANGLERC
Remote controller for XT-ANGLE with bright display (cable included, 10 m in length)
XT-D8P
Connection panel specially designed for line arrays
XT-PSB32/8
Patch board 32A - 2 XLR IN, 2 XLR OUT - 4 Speakon OUT NL8MPR - 3 rack units
XT-NETINT
Network Interface for XT-NET connection (PC adapter: from USB or RS232 to standard RJ45)
XT-NETPS
Power unit for supplying up to 2 XT-NETINT (if a RS232 is used)
XTMISIS-SK
Wheelboard for XTMISIS and XTMISIS/A double subwoofer
