Step 2: Install the Mount Kit (PMAX-0110)
1.
Insert the cables from the tube into the mount kit and route them to pass through the outer
bracket.
2.
Align the slot of the mount kit to the tab inside the straight tube and install the mount kit.
3.
Twist the mount kit to align the screw holes and attach the two (2) mounting screws (included
in the mount kit package).
