Allmand Brothers NIGHT LITE PRO V - Manual (Page 15)

LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
24
20 21 16
23
22
17 18 19
10 8
9
6
7
2
11
12
4
13
14 15
25
26
3
2
29 18 19
28 27 2
5
10 30 15
31
32
NO. QTY. PART NO. DESCRIPTION
1 1 433328 1/2" PLASTIC PLUG
2 12 044023 1/4-20 NYLOCK NUT
3 2 041047 1/4-20 X 3/4 PH CSK
4 4 100071 3/16 CABLE BOLT
5 4 041070 1/4-20x3/4 TAP SCREW
6 8 047005 1/4 FLAT WASHER
7 8 043060 3/8 INT STAR WASHER
8 4 100089-15 COVER, CORNER BLOCK
9 8 046020 1/4-20 X 1 1/4" HEX BOLT
10 4 100088 BLOCK, CORNER FRICTION
11 2 100062 SPACER, 3/8" UHMW
12 4 041023 #10 X 3/8 PLS
13 1 100160 2 1/2" PULLEY
14 1 100642 5/8 X 1 SHOULDER BOLT
15 2 044048 NUT NYLOCK 1/2-13 HEX PL
16 2 045044 PIN, COTTER
17 1 101378 1/2 X 2 SH BOLT
18 2 047010 5/16 FLAT WASHER
19 2 044038 3/8-16 NYLON INSERT NUT
20 2 101377 CLEVIS PIN 7/16 X 1 1/2"
21 2 047015 3/8 FLAT WASHER
22 2 101374-15 BEARING CAGE
23 2 101380 COMPOSITE ROLLER
24 1 101035-15 SECTION 2
25 1 100204-15 SEC 2 ROLLER PLATE
26 2 101626 FRICTION PLUG
27 2 041050 1/4-20 X 3/4 TRUSS BOLT
28 2 310212 CLAMP CUSH #10 1/4 HOLE
29 1 101379 1/2 X 2.75 SH BOLT
30 1 100202 5/8 X 6 SS SH BOLT
31 2 100203 ROLLER
32 1 101034-15 SECTION 1
NIGHT-LITE PRO V-SERIES DOMESTIC
B-1K
HYDRAULIC TOWER SECTIONS
B-1K
