LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
7
8
18 19
3 20
4 5
23 22 21
6
24
27
25
26
15 1 2
17 1 16
12
10
39
11
9
14 1 13
30
34 32
16 1 33
29
38 37
36
33 32
28
35 1 2
NO. QTY. PART NO. DESCRIPTION
1 32 047010 5/16 FLAT WASHER
2 10 044033 5/16 NYLOCK NUT
3 2 650567P SHROUD, RADIATOR LEFT/RIGHT
4 4 041050 1/4-20 X 3/4 TRUSS BOLT
5 4 044023 1/4-20 NYLOCK NUT
6 1 650830 LOMBARDINI LDW 1003 W/HOUR METER
7 1 100984 LOMBARDINI MUFFLER
8 1 100707P MUFFLER BRACKET
9 1 100129P WELD, ENGINE PLATE
10 4 100152P ENG. MT SPACER
11 1 650562P ENGINE MOUNT LDW 1003
12 4 650259 RUBBER ENG MT - 120 LB
13 4 044036 3/8-16 KEPS NUT
14 4 046110 3/8-16 X 1" HHCS GR5 PLATED
15 8 053022 5/16-18 X 1 1/4 CARR BOLT
16 8 044038 3/8-16 NYLON INSERT NUT
17 4 046134 3/8-16 X 2 1/2 GR 8 HEX BOLT
18 1 046015 1/4-20 X 1 HEX BOLT
19 1 044021 1/4-20 KEPS NUT
20 1 030052 TRIMLOCK
21 12 047070 WASHER, FLAT 1/4" SS
22 6 043020 1/4" SPLIT LOCK WASHER
23 6 042019 6mm X 1.0 X 16mm GR 8.8 HEX BOLT
24 1 100901 LOMBARDINI FUMOTO VALVE
25 1 100601 JIC 90 DEG FITTING
26 1 100602 JIC CAP
27 1 081017 3/8" YEL HOSE 20"
28 1 100349 MECC ALTE GENERATOR 6KW 50 HZ
29 1 100352P BOTTOM PLATE
30 1 100353P TOP PLATE
31 1 100354P BACK PLATE
32 8 043065 3/8 SPLIT LOCK WASHER
33 8 046115 3/8-16 X 1 1/4 HHCS
34 4 046120 3/8-16 X 1 1/2 HEX BOLT
35 2 046055 5/16-18 X 1 1/4 HHCS
36 1 100614 5/16-18 T-SLOT NUT
37 1 047016 3/8 SAE FLAT WASHER
38 1 042040 10mm X 1.5 X 30mm HEX BOLT GR 8.8
39 6 046041 5/16 - 18 X 1/2"
NIGHT-LITE PRO V-SERIES DOMESTIC
C-2B
LOMBARDINI
C-2B
