LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
KUBOTA DEEP SEA
CONTROL PANEL
NO. QTY. PART NO. DESCRIPTION
1 1 433329 5/8" PLASTIC PLUG
2 1 433328 1/2" PLASTIC PLUG
3 2 041078 1/4-20 X 1/2 PH TRUSS SCREW
4 4 044021 1/4-20 KEPS NUT
5 1 041070 1/4-20x3/4 TAP SCREW
6 2 046010 1/4-20 X 3/4 HEX BOLT SS
7 1 101065 DEEP SEA CONTROLLER
8 1 100957P GAUGE PANEL, DEEP
9 1 650363P COVER PANEL GUAGE
10 1 340009 SWITCH 15 AMP SPST
9
14
8
13 11
10
4
12 17
1
5
6
7
NO. QTY. PART NO. DESCRIPTION
1 1 100991 KUBOTA D1105 50Hz W/DEEPSEA PANEL, BOX MUFFLER
2 1 340302 HIGH TEMP SWITCH KUBOTA
3 1 340301 OIL PRESSURE SWITCH KUBOTA
4 1 352139 KUBOTA BOX MUFFLER
5 1 920745 KUBOTA FUEL FILTER
6 1 920743 KUBOTA OIL FILTER
7 1 650001 RADIATOR KUBOTA
8 1 653113 ARC GEN EXHAUST
9 1 653114 ARC GEN REAR
10 1 651233P BOX MUFFLER REAR
11 2 043050 WASHER LOCK
12 1 352135 EXHAUST GASKET KUBOTA
13 2 042018 6mm X 10mm HEX BOLT GR 8.8
14 2 713086 CLAMP 1 3/8" MUFFLER
15 8 047016 3/8 SAE FLAT WASHER
16 8 042038 10mm X 1.25 x20mm GR 8.8 HEX BOLT
17 1 650290 AIR FILTER ELEMENT KUBOTA
KUBOTA DEEP SEA CONTROL PANEL
KUBOTA ENGINE PARTS
NIGHT-LITE PRO V-SERIES DOMESTIC
C-4D
KUBOTA CONTROLS
C-4D
