Page 17
LEGEND:
NS=NOT SHOWN
WHEN ORDERING,SPECIFY THE
COLOR WANTED ON PARTS
CONTAINING THE LETTER "P"
20
33
26
22
27
25
18
14
17
15
16
19
21
13
31
12
9
10
12
9
5 8
5
11
8
3
7
23
12
9
31 32 9
30
12
9
6
4 7
24
8
11
29 12 28
7
NO. QTY. PART NO. DESCRIPTION
1
1 101382
SWITCH BOOT
2
1 022025
2-SCREW ROMEX CLAMP, 3/4"
3
4 041024
RHMS 10-24 X .5
4
4 041027
10-24 x 3/4" PHILIPS HEAD MS
5
4 041050
1/4-20 X 3/4 TRUSS BOLT
6
2 044004
6-32 KEPS NUT
7
8 044016
10-24 KEPS NUT
8
4 044021
1/4-20 KEPS NUT
9
11 044036
3/8-16 KEPS NUT
10
4 046110
3/8-16 X 1" HHCS GR5 PLATED
11
2 043050
WASHER LOCK
12 19 047010
5/16 FLAT WASHER
13
3 064035
1 1/2" CAPLUG
14
1 100109P COVER, ELEC WINCH
15
1 100110P BASE, ELEC WINCH COVER
16
1 100123P BRACKET, TOWER ANGLE
17
1 100146
ASSY, ELEC WINCH
18
1 100158P SWITCH BRACKET
19
2 100164
SWITCH - TWR LIMIT
20
1 100165P LIMIT SW MT & COVER
21
1 100641
90 DEGREE FLEXCON
22
1 100662
ALARM TWR VERTICAL
23
3 100670
3/8-16 X 1 1/4 CARR BOLT
24
4 310212
#10 CUSHION CLAMP
25
1 310544
SWITCH MOMENTARY DPDT
26
1 101222
RECT POLY PLUG
27
1 100610
CIRCUIT BREAKER 5 AMP
28
4 044031
5/16 -18 KEPTS NUT
29
4 046050
BOLT CS 5/16-18 X 1 HEX GR5 PL
30
1 046115
3/8-16 X 1 1/4 HHCS
31
3 046120
3/8-16 X 1 1/2 HEX BOLT
32
4 047015
3/8 FLAT WASHER
33
1 100118-15 WELD, LIFT BAR
NI HT LITE R
ERIE
E TIC
B-2B
ELECTRIC WINCH
B-2B
