Ignite SDC/HDC Robotic Camera Instruction Manual
87
Menu Selections
Detail Menu
The DETAIL menu is shown in
. Menu selections are described in
.
Figure 58. DETAIL Menu
Table 39. DETAIL Menu Selections
Selection
Description
DETAIL [OFF, ON]
For turning all the detail functions ON or OFF.
TOTAL DTL LEVEL [–31 to +31]
For setting the H DTL and V DTL levels.
H DTL LEVEL [0 to 63]
For setting the H DTL level.
CRISP [0 to 31]
For setting the noise elimination level of the detail signals.
LEVEL DEPENDENT [0 to 15]
For removing the detail in the dark areas.
PEAK FREQUENCY [00 to 31]
For setting the H DTL peak frequency.
KNEE APERTURE [OFF, ON]
For turning the emphasizing of the outlines for the high-brightness areas
ON or OFF.
KNEE APE LEVEL [0 to 5]
For adjusting the knee aperture level.
SLIM DETAIL [OFF, ON]
For setting the detail more finely at ON.
DETAIL(+) [–31 to +31]
For adjusting the detail gain in the + direction.
DETAIL(–) [–31 to +31]
For adjusting the detail gain in the – direction.
DETAIL CLIP [0 to +63]
For minimizing the glare caused by adding too much detail as a result of a
detail clip adjustment.
DETAIL SOURCE
[(G+R)/2, (G+B)/2, (2G+B+R)/4,
(3G+B)/4, R, G]
For setting the ratio of the RGB signal components which create the detail.
DETAIL (1/2)
DETAIL
:ON
TOTAL DTL LEVEL
:+00
H DTL LEVEL
:11
CRISP
:02
LEVEL DEPENDENT
:2
PEAK FREQUENCY
:10
KNEE APERTURE
:ON
KNEE APE LEVEL
:3
DETAIL (2/2)
SLIM DETAIL
:OFF
DETAIL (+)
:+00
DETAIL (-)
:+00
DETAIL CLIP
:00
DETAIL SOURCE
:(G+R)/2
**
**
**
**
8492_50_r0
