JEP-100 — Installation and Operating Manual 57
Operation
Salvo Switching
Note The JEP-100 Salvo function requires Jupiter version 7.4 software (or newer)
to be operating in the CM-4000.
The SALVO key can be used to execute a list of pre-built Jupiter sequences,
where a sequence is a switch of one or more sources to one or more destina-
tions.
Setting Up a Sequence
A Jupiter sequence is built using the Jupiter Sequence Set table, an
example of which is shown in
Figure 21 .
Figure 21. Sequence Set
The sequence set is given an eight-character (max) name and is of type
"3800."
In this example, sequence set "SETUP" contain two sequences: "SET UP1"
and "SETUP2." "SETUP1" will switch Cameras 1 through 3 into Monitors 1
through 3 (a total of three switches) with a single TAKE command.
"SETUP2" will reverse the order of the cameras in the monitors. Each
sequence can include up to 25 events (switches).
There is no specific limit to the number of sequences, but due to memory
restrictions a limit of 16 is recommended (e.g., "SETUP1" through
"SETUP16."
The sequence set must be assigned to the JEP-100 panel on the Jupiter MPK
Devices
table.
For additional information regarding Jupiter sequences and assigning
them to control panels, refer to the CM-4000 manual.
SETUP1
8536_22
CAM1
SETUP1 CAM2
1
2
SETUP1 CAM3
SETUP2 CAM1
3
4
SETUP2 CAM2
SETUP2 CAM3
5
6
Sequence
Input
Logical
Sequence Set - SETUP
MON1
MON2
MON3
MON3
MON2
MON1
Output
Logical
YYYY
Levels
YYYY
YYYY
YYYY
YYYY
YYYY
