23
Kaleido-IP X300/X100
Quick Start Guide
Refer to Managing Transport Streams in a Kaleido-IP System Representation, in the Kaleido-X
User’s Manual, for instructions on:
• importing transport stream configuration information, from a spreadsheet
• adding source-specific or source-filtered multicast (SSM or SFM) transport streams
• adding HLS playlists
• adding RTSP transport streams
Adding a Multicast Transport Stream
To add a multicast transport stream
1 In the main window, click the System tab, and then click Description/Calibrations on
the second level tab bar.
2 Expand the System hierarchical list, right-click the appropriate network adapter for the
source you wish to add, and then click insert Multicast.
The Multicast Stream Configuration window appears.
3 In Multicast Stream Configuration, replace the default stream name if desired, select
the appropriate protocol (RTP, UDP), and type the multicast group address and port
number associated with the transport stream you wish to add.
Notes
• The Kaleido-X Software supports UTF-8 encoded stream names. The only
characters, which cannot be used in a stream name are: @ / \ ' and " .
• Verify the protocol you selected. Registering an RTP stream as UDP instead
of RTP may result in the decoded video appearing jerky or accelerated on
the monitor wall.
