24
Setting Up the Kaleido-IP
System Setup
4 If the stream you wish to add is constrained to a virtual LAN, select Virtual LAN
tagging, and then type the appropriate VLAN identifier.
5 Click OK.
The Kaleido-IP establishes a connection with the selected stream. All programs that are
part of the stream, and the elementary streams included in these programs,
automatically appear under the transport stream element in the System list.
6 Repeat this procedure until you have added all required multicast transport streams to
your system configuration.
7 On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Changes to the system are saved.
Note: VLAN adapter settings must have been previously configured in
XAdmin. Refer to Configuring Virtual Network Adapters on a Kaleido-IP, in the
Kaleido-X User’s Manual, for more information.
Note: Under the network adapter elements, transport streams are listed in
alphabetical order.
Transport stream
Program 1
Elementary streams (audio)
Elementary stream (video)
Group address
Protocol
Port number (or range)
Program 2
Elementary stream (video)
Elementary streams (audio)
