Kaleido-X16 Installation
The Kaleido-X16 is a 1RU, multi-image display processor with high image quality and a rich
feature set. This chapter contains physical descriptions, installation instructions and
connection information for the Kaleido-X16 frame.
Summary
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mechanical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Frame and Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CompactFlash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Signalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Introduction
The Kaleido-X16 system is a cost-effective multi-image processor. It can accommodate
smaller systems or scale up to production systems, where smaller building blocks with
fewer input counts per display are desirable. Each chassis can display up to 16 auto-sensing
HD, SD, or Analog inputs that can be displayed across two high resolution outputs at
multiple sizes.
Features
Small form factor 1RU
Expandable Expandable multi-room architecture, based on a chassis with 16 inputs,
and 2 independent multi-image display outputs
Unmatched
flexibility Any source can be repeated to any position, to any display, at any size, at
any resolution, without blocking or grouping restrictions
