24

Specifications

DVI Graphic Inputs

DVI Graphic Inputs

The Kaleido-X16 supports two DVI inputs, one for each of two output heads.

Formats

720p24, 720p25, 720p29.97, 720p50, 720p59.94
1080i50, 1080i59.94
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97
1080p23.98, 1080p24, 1080p25, 1080p29.97

Note:

The Kaleido-X software does not distinguish between

1080PsF25 and 1080i50, and neither between 1080PsF29.97 and
1080i59.94. Both 1080PsF25 and 1080i50 are reported as 1080i50,
and both 1080PsF29.97 and 1080i59.94 are reported as
1080i59.94, on the monitor wall and in XAdmin’s Status and
Options page.

Audio

SMPTE ST 299-1

Return loss

>15 dB up to 1.485 GHz

Jitter

< 0.2 UI

Cable length

100 m (328 ft) (Belden 1694A)

3Gbps Inputs

Signal

4:2:2 SMPTE ST 424:2006 (2.97/1.001 Gbps)

Formats

1080p50

1080p59.94

Audio

SMPTE ST 299-1

Return loss

> 15 dB up to 1.485 GHz

> 10dB up to 2.97GHzß

Jitter

< 0.2 UI

Cable length

100 m (328 ft) (Belden 1694A)

Graphics converted to HD-SDI from KXI-DVI-Bridge

Signal

SMPTE ST 292-C (1.485, 1.485/1.001 Gbps)

Formats

1024 × 768 @ 60 (XGA)
1280 × 1024 @ 60 (SXGA)
1366 × 768 or 1368 × 768 @ 60 (WXGA)
1680 × 1050 @ 60 (WSXGA+)
1600 × 1200 @ 60 (UXGA)

Cable length

100 m (328 ft) (Belden 1694A)

HD-SDI Inputs (continued)

Signal

DVI-D (single link)

Resolution

From 1024 × 768 to 1920 × 1200 NI
