29
Kaleido-X16
Hardware Description & Installation Manual
Frame
GPI OUTPUT (up to 4)
Description Contact closure to GND
Signal Open collector 5 to 12 VDC
Contact closure current 50 mA max
Reverse voltage -15 Volts max
Reverse current -50 mA max
V out low 0.6 Volts at 1.5mA
Connector DB-44
Ethernet
Signal 10/100 BASE-T (IEEE 802.3)
Connector RJ-45
RS-422
Signal RS-422 (SMPTE ST 207, EBU-3245)
Connector RJ-45
USB
Signal USB Version 1.0
Connector USB
Power supply Hot-swappable redundant power supply
Input voltage 100-240 V
Frequency 47.63 Hz
Power 300 W @ 75% of PSU
Max current 4 A
Max power 300 W
Dimensions H: 45 mm (1.75 in) (1 RU)
W: 451 mm (18 in) + mounting flange for standard 19-inch rack
D (with cover and connectors): 641 mm (25.25 in)
D (without cover and connectors): 591 mm (23.25 in)
Full spec. temp. range 0-40 °C (ambient)
Storage humidity 90% RH non-condensing
Functional humidity 65% RH non-condensing
