51
NV9607
User’s Guide
Panel Submenu
The panel submenu appears when you press button 3 under the main menu:
The panel menu presents 2 additional submenus:
• Panel ID. (Press button 1.)
• Button illumination. (Press button 2.)
Press button 23 to return to the main menu or button 24 to exit menu mode.
Panel ID Submenu
The panel ID submenu appears when you press button 1 under the panel menu:
The panel ID menu shows the current panel ID and allows you to change the panel ID using a
“numeric keypad” comprising the top left 10 buttons. In addition, buttons 20 and 21 act as
‘Cancel’ and ‘Save’ buttons:
Note that the numeric keys range from 0 (at the left) to 9.
Press button 20 to cancel the new panel ID; press button 21 to save it.
Press button 23 to return to the panel menu or button 24 to exit menu mode.
Panel Menu Panel ID 1
Illumination 2
Main Menu 23
Exit 24
Panel ID 6071 CANCEL 20
SAVE 21
Panel Menu 23
Exit 24
24 23 21 20 1 0 3 2 5 4 7 6 9 8
Main Menu Software 1
User 2
Panel 3
Exit 24
