Chapter 11 Parts removal and replacement
108 Profile XP Service Manual 23 July 2004
19. When the Master Drive Configuration box appears, perform one of the following
steps:
- If the PRIMARY drive was replaced, highlight Rebuild drive on
Primary Channel , then press Enter .
- If the MIRROR drive was replaced, highlight Rebuild drive on the
Mirror Channel , then press Enter .
The Copy Drive dialog box appears displaying drive copy status and estimated
completion time. Primary and Mirror drive LEDs appear orange while the Master
LED flashes red.
20. When the status message appears indicating the drives are identical, remove the
bootable DupliDisk Utilities diskette.
21. Exit the DupliDisk DUPLI Mirroring Utility and reboot as follows:
a. Use the arrow keys to select the Exit, then press Enter .
b. In the confirmation dialog box that appears type Y (to select Yes), then press
Enter .
c. Press Enter again to continue, which reboots the system from the Primary system
drive to start Windows NT.
Creating a bootable DupliDisk Utilities diskette
You must create your own DupliDisk Utilities diskette that allows you to replace
failed drives on your Profile XP system. To create the diskette:
1. Insert the DupliDisk3 DupliCD into the CD-ROM drive and start Menu if autostart
is not enabled on your system.
2. Insert a blank diskette into the floppy disk drive.
3. From the DupliDisk main menu, choose DOS Boot Disk Creator . (If the button does
not open the DOS Boot Disk Creator, start the application from \DOS\DOS_Boot
_Disk_Maker _for_Windows\BOOTUTIL1_2.exe.on the CD-ROM.)
4. Follow the on-screen prompts to create the bootable floppy diskette, over-writing
all existing data on the diskette.
You can now use this bootable diskette when replacing a defective system drive.
