Section ― Hardware Setting
32
STORM 3G ELITE ― Setup Guide
2
Use the attached USB cable to connect the USB
terminal of your PC and that of STORM 3G Elite
PCI Express Expansion board.
USB cable for USB audio
STORM 3G Elite PCI
Express Expansion board
3
Use the attached STORM 3G Elite Desktop PC
connection cable to connect STORM 3G Elite PCI
Express Expansion board and STORM 3G Elite.
STORM 3G Elite PCI
Express Expansion board
STORM 3G Elite
STORM 3G Elite Desktop
PC connection cable
4
Connect other devices to STORM 3G Elite if
necessary.
When the connection of devices has completed, close
the cover of the PC.
