 STORM 3G ELITE ― Setup Guide
Section
5
Hardware Specifications
STORM 3G Elite
Video input
SDI in
BNC x2 (SMPTE 424M *1 / 292M / 259M-C)
HDMI in HDMI Connector (HDMI 1.3 compatible)
Y/Pb/Pr in or Y/C in BNC x3
CVBS in BNC x1
Video output
SDI out
BNC x2 (SMPTE 424M *1 / 292M / 259M-C)
HDMI out HDMI Connector (HDMI 1.3 compatible)
Y/Pb/Pr out or Y/C
out BNC x3
CVBS out BNC x1
Audio input
SDI in
Embedded audio 8ch (SMPTE 299M / 272M-A)
HDMI in HDMI Connector (HDMI 1.3 compatible)
8ch, 32/44.1/48KHz, Unlocked/Locked *2
AES/EBU in BNC x4 (ch 1/2, ch 3/4, ch5/6, ch7/8)
32/44.1/48KHz, Unlocked/Locked
Balanced Audio in XLR-3-31 compatible x 4 (ch1 to 4)
(Termination resistance: 600Ω)
Voice Over in XLR-3-31 compatible x 1 (Mic / Line
switchable)
48V Phantom power supply available
Capture as USB audio device available
