Specifications
Transmitter Inputs
Interface: ............................................................................................................... Digital optical
Input wavelength range: ............................................................................1250 to 1650 nm
Input optical power range: ............................................................................. -2 to -22 dBm
Input optical connector: .........................................................................................................ST
Maximum data rate, per channel: .............................................................................. 3 Gbps
Transmitter Output
Interface:................................................................................................ Digital optical, CWDM
Output wavelengths:
1300 nm range standard: 1271, 1291, 1311, 1331, 1351, 1371, 1411 and 1431 nm
1500 nm range optional: 1471, 1491, 1511, 1531, 1551, 1571, 1591 and 1611 nm
Output power, per channel, typical: ......................................................-3 dBm (±3 dBm)
Receiver CWDM
Input wavelengths:
1300 nm range standard: 1271, 1291, 1311, 1331, 1351, 1371, 1411 and 1431 nm
1500 nm range optional: 1471, 1491, 1511, 1531, 1551, 1571, 1591 and 1611 nm
Mechanical/Environmental
Dimensions (LxWxH) .........................................................................................8"x17.5"x1.75"
Weight, each end................................................................................................................... 5 lbs
Connectors: Optical ...................................................................................................................ST
Input voltage............................................................................................................... 12-18 VDC
Power consumption ......................................................................................................... <25 W
Indicators................................................... Power ON, SDI Data Presence, Optical Power
Temperature Range ...............................................................................................-20° to 55 °C
Humidity Range ..........................................................................0 to 95 % non-condensing
Compliance
Laser Safety.............................................................................................................. Class 1 Laser
EMI/RFI....................................................................................Complies with IEC/EN 60825-1
Certifications ..........................................................................................................................RoHS
