Operating
Parameters
List of operating parameters
P00 CODE Enter code number
9 51 48:
Change protected operating parameters
66 55 44: Display the software version (in the X axis)
Display the date of release (in the Y axis)
10 52 96: Multipoint axis error compensation
P01 Unit of measure 1)
Display in millimeters MM
Display in inches
INCH
P03.1 to P03.3 Radius/diameter display 1)
Display position value as radius RADIUS
Display position value as diameter DIAMETER
P11 Activate scaling factor 1)
Active SCALING ON
Not active SCALING OFF
P12.1 to P12.3 Define scaling factor 1)
Enter a scaling factor separately for each axis:
Entry value > 1: workpiece will “grow”
Entry value = 1: workpiece will remain the same size
Entry value < 1: workpiece will “shrink”
Input range: 0.100000 to 9.999999
Default setting: 1.000000
P13.1 to P13.3 Shrinkage compensation
Input range (µm): -99999 to +99999
Default setting: 0
Example: Input value = 2% corresponds to 20 000 µm/m
Please note: If you use the shrinkage compensation in
addition to the linear compensation, the compensation
values will superimpose each other multiplicatively.
P17 MIN.P2.1
2nd trigger point before MIN position, switching output A2
Input range: 0 to + 99999.9999 mm
Default setting: 0
P 18 MIN.P2.2
2nd trigger point for output A2
Input range: 0 to + 99999.9999 mm
Default setting: 0
In parameter P20, you select the trigger point to be effective
for output A2 (trigger point defined in P17 or P18).
1) User parameter
