4
Foot switch
MSE 1114
1
2
3
4
5
6
7
8
9
Switch 1
NO
/
/
/
GND
Switch 2
NO
/
DC 3.3 V
GND
5
RJ45
MSE 1114
1
2
3
4
5
6
7
8
E0 Tx +
E0 Tx –
E0 Rx +
/
/
E0 Rx –
/
/
6
EnDat
8-pin coupling, M12
Power supply
Absolute position values
8
2
5
1
3
4
7
6
U
P
Sensor
U
P
0 V
Sensor
0 V
DATA
DATA
CLOCK
CLOCK
173
