8.3 Cycles for Milling Pockets,
Studs and Slots
Overview
Cycle Soft key
4 POCKET MILLING (rectangular)
Roughing cycle without automatic pre-positioning
212 POCKET FINISHING (rectangular)
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
213 STUD FINISHING (rectangular)
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
5 CIRCULAR POCKET
Roughing cycle without automatic pre-positioning
214 C. POCKET FINISHING
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
215 CIRCULAR STUD FINISHING
Finishing cycle with automatic pre-positioning,
2nd set-up clearance
210 SLOT RECIP. PLNG
Roughing/finishing cycle with automatic pre-
positioning, with reciprocating plunge infeed
211 CIRCULAR SLOT
Roughing/finishing cycle with automatic pre-
positioning, with reciprocating plunge infeed
