Comparison: Touch probe cycles in the Manual and Electronic Handwheel modes
Cycle TNC 320 TNC 310 iTNC 530
Calibrate the effective length
Calibrate the effective radius
Measure a basic rotation using a line
Set the datum in any axis
Set a corner as datum
Set the center line as datum J J
Set the circle center as datum
Measure a basic rotation using two holes/cylindrical studs J J
Set the datum using four holes/cylindrical studs J J
Set circle center using three holes/cylindrical studs J J
