Task: Program(s):
HEIDENHAIN Basic Course ISO G 426
Contour cycles SL II,
Kidney-shaped island
F06 62191/1
100
100
0
60
0
50
20
0
30
15
R75
R20
R10
R80
18
P2
P1
P4
P3
Point X
6.645
55.505
Y
35.495
69.488
P
1
P
2
Point X
58.995
19.732
Y
30.025
21.191
P
3
P
4
