5 Set the datum
„ Manually by touching the workpiece with the tool in the untilted
coordinate system (see “Datum Setting (Without a 3-D Touch
Probe),” page 78).
„ Controlled with a HEIDENHAIN 3-D touch probe (see the Touch
Probe Cycles Manual, chapter 2).
„
Automatically by using a HEIDENHAIN 3-D touch probe (see the
Touch Probe Cycles Manual, chapter 3).
6 Start the part program in the operating mode Program Run, Full
Sequence
7 Manual Operation mode
Use the 3-D ROT soft key to set the TILT WORKING PLANE function
to INACTIVE. Enter an angular value of 0° for each axis in the menu
(see “Activating manual tilting,” page 91).
