Overview tables
Cycles
Cycle
number
Cycle designation
DEF-
active CALL-
active
Page
7 Datum shift „ Page 487
8 Mirror image
„
Page 493
9 Dwell time „ Page 506
10 Rotation „ Page 495
11 Scaling factor „ Page 496
12 Program call „ Page 507
13 Oriented spindle stop
„
Page 508
14 Contour definition „ Page 429
19 Tilt working plane „ Page 498
20 Contour data SL II „ Page 433
21 Pilot drilling SL II „ Page 434
22 Rough out SL II
„
Page 435
23 Floor finishing SL II „ Page 437
24 Side finishing SL II
„
Page 438
25 Contour train „ Page 439
26 Axis-specific scaling „ Page 497
27 Cylinder surface „ Page 441
28 Cylindrical surface slot „ Page 443
29 Cylinder surface ridge
„
Page 443
30 3-D data „ Page 472
32 Tolerance „ Page 509
39 Cylinder surface external contour „ Page 448
200 Drilling „ Page 335
201 Reaming
„
Page 337
202 Boring „ Page 339
203 Universal drilling
„
Page 341
