17 mod functions, Mod functions – HEIDENHAIN iTNC 530 (340 49x-06) ISO programming User Manual
Page 50
50
17.1 Selecting MOD Functions ..... 542
Selecting the MOD functions ..... 542
Changing the settings ..... 542
Exiting the MOD functions ..... 542
Overview of MOD functions ..... 543
17.2 Software Numbers ..... 544
17.3 Entering Code Numbers ..... 545
17.4 Loading Service Packs ..... 546
17.5 Setting the Data Interfaces ..... 547
Setting the RS-232 interface ..... 547
Setting the RS-422 interface ..... 547
Setting the OPERATING MODE of the external device ..... 547
Setting the baud rate ..... 547
Software for data transfer ..... 549
17.6 Ethernet Interface ..... 551
Connection possibilities ..... 551
Connecting the iTNC directly with a Windows PC ..... 552
17.7 Configuring PGM MGT ..... 562
Changing the PGM MGT setting ..... 562
17.8 Machine-Specific User Parameters ..... 564
17.9 Showing the Workpiece in the Working Space ..... 565
Rotate the entire image ..... 566
17.10 Position Display Types ..... 567
17.11 Unit of Measurement ..... 568
17.12 Selecting the Programming Language for $MDI ..... 569
17.13 Selecting the Axes for Generating G01 Blocks ..... 570
