New functions in version 60642x-02
New function for opening 3-D data (software option) directly on the
TNC (see "Opening 3-D CAD data (software option)" page 296 ff)
Improvement of Dynamic Collision Monitoring (DCM):
Chucking equipment archives can now be activated (see "Loading
fixtures under program control" on page 426) and deactivated (see
"Deactivating fixtures under program control" on page 426) under
program control
The display of stepped tools has been improved
When you select tool carrier kinematics, the TNC now displays a
graphical preview of the carrier kinematics (see "Assigning the
tool-carrier kinematics" on page 194)
Extension of the functions for multiple axis machining:
In the Manual Operation mode you can now move the axes even
if TCPM and Tilt Working Plane are active at the same time
You can now also change tools when M128/FUNCTION TCPM is active
File management: archiving of files in ZIP archives (see "Archiving
The nesting depth for program calls has been increased from 6 to 10
(see "Nesting depth" on page 306)
smarT.NC units can now be inserted anywhere in plain-language
programs (see "smartWizard" on page 467)
There is now a search function based on tool names available in the
tool selection pop-up window (see "Search for tool names in the
selection window" on page 200)
Improvements in pallet machining:
The new column FIXTURE has been added to the pallet table to be
able to activate fixtures automatically (see "Pallet operation with
tool-oriented machining" page 550 ff)
The new workpiece status SKIP has been added to the pallet table
(see "Setting up the pallet level" page 556 ff)
If a tool sequence list is created for a pallet table, the TNC now
also checks whether all the NC programs of the pallet table are
