740
M109
M110
M111
Constant contouring speed at tool cutting edge
(increase and decrease feed rate)
Constant contouring speed at tool cutting edge
(feed rate decrease only)
Reset M109/M110



Page 394
M114
M115
Automatic compensation of machine geometry when working with tilted axes
Reset M114


Page 521
M116
M117
Feed rate for rotary axes in mm/min
Reset M116


Page 518
M118 Superimpose handwheel positioning during program run  Page 397
M120 Pre-calculate radius-compensated contour (LOOK AHEAD)  Page 395
M124 Do not include points when executing non-compensated line blocks  Page 388
M126
M127
Shortest-path traverse of rotary axes
Reset M126


Page 519
M128
M129
Retain position of tool tip when positioning tilting axes (TCPM)
Reset M128


Page 523
M130 Moving to position in an untilted coordinate system with a tilted working plane  Page 386
M134
M135
Exact stop at nontangential contour transitions when positioning with rotary axes
Reset M134


Page 526
M136
M137
Feed rate F in millimeters per spindle revolution
Reset M136


Page 393
M138 Selection of tilted axes  Page 526
M140 Retraction from the contour in the tool-axis direction  Page 398
M141 Suppress touch probe monitoring  Page 399
M142 Delete modal program information  Page 400
M143 Delete basic rotation  Page 400
M144
M145
Compensate the machine's kinematics configuration for ACTUAL/NOMINAL positions
at end of block
Reset M144


Page 527
M148
M149
Retract the tool automatically from the contour at NC stop
Reset M148


Page 401
M150 Suppress limit switch message (function effective blockwise)  Page 402
M200
M201
M202
M203
M204
Laser cutting: Output programmed voltage directly
Laser cutting: Output of voltage as a function of distance
Laser cutting: Output of voltage as a function of speed
Laser cutting: Output of voltage as a function of time (ramp)
Laser cutting: Output voltage as a function of time (pulse)





Page 403
M Effect Effective at block Start End Page
