17
IK 5000 QUADRA-CHEK
Installation Instructions
Operating Instructions available at www.heidenhain.de
3. Specifications
The IK 5000 QUADRA-CHEK is a family of Windows
®
PC based products for conducting
precision dimensional measurements of 2D and 3D parts on comparators, coordinate
measuring systems and measuring microscopes. Systems are available in versions for 3
or 4 axes and support manual part positioning and measurement under user control, or
CNC part positioning and automated measurement under program control. This product
is designed for indoor use only. The IK 5000 QUADRA-CHEK components shall only
be installed as described in these instructions. Installation and maintenance are to be
performed by qualified personnel only.
Specifications
Power input
PCI connector to PC G :
DC 5 V (± 5 %), DC 12 V (± 5 %), DC -12 V (± 5 %)
IK 5000 card power connector E : DC 5 V (± 5 %), DC 12 V (± 5 %)
Input frequency
XYZ A , Q H :
» 1 V
PP
differential: max. 3.6 MHz
« TTL differential: max. 5.1 MHz
« TTL single-ended: max. 2.2 MHz
Power consumption
IK 5000 card
+12 V: 3600 mW
-12 V: 1200 mW
+5 V: 6250 mW
+3.3 V: 1650 mW
total: 12700 mW
XYZ A , Q H : max. 375 mW
XYZ B : max. 650 mW
Q J : max. 500 mW
Zoom N: rated 600 mW
Light K : rated 800 mW
Specification: PCI local bus Spec. Rev. 2.2
Connector: PCI V / 32-bit connecting element
PCI component: PCI 9030 from PLX, target interface (slave)
Identifier in component PCI 9030
Vendor ID:
0x10B5
Device ID: 0x2065
Environmental conditions
Operating temperature:
0 °C ... 55 °C
Storage temperature: -30 °C ... 70 °C
Relative humidity: † 80 %
ID 678414-xx
ID 678415-xx ID 678416-xx
ID 678419-xx
ID 678417-xx
ID 678418-xx
ID 678420-xx
ID 678421-xx ID 678422-xx
Mass: 122 g 184 g 150 g 190 g
