11
Motherboard Information
Chapter 2
Network Application Platforms
Power Debug Port(psvid_p1)
Selection between PCI-E Reset and System Reset (J16):
A 1x3 (2.54mm) pin header for PCI-E reset and system
reset function.
Front LCD Module Connector(J14): A 2x5 (2.00mm) pin
header for connecting the front system LCD display.
Hardware or Software Reset Jumper(J13, right next to
SW2): The jumper can be adjusted to be in either hardware
or software reset mode when the reset switch is pressed.
The hardware reset will reboot the system without turning
off the power. The software reset can be programmed to
reset software to its default settings.
Clear CMOS jumper (J8): It is for clearing the CMOS
memory and system setup parameters by erasing the data
stored in the CMOS RAM such as the system passwords.
DIMM Socket (J3, J4): The 240-pin DDR3 DIMM is for
connecting the DDR3 1066/1333 memory. The system
can support up to 16 GB in maximum and Dual-channel
architecture. Dual channel doubles data throughput
from the memory to the memory controller by maximize
memory throughput from 64-bit buses to 128-bit bus.
SATA 1 and 2 Connectors (SATA1, SATA2): It is for
connecting a 2.5’’ SATA hard disk to be served as your
system’s storage. The system can support a maximum of
2 disks. It conforms with SATA II (3.0 Gbs).
Console Port Cconnector (COMB1)
SPI-ROM Update Connector (SPI-ROM1): Using the
appropriate cable to connect this 10-pin ISP header
connector, the SPI Flash soldered on board can be
updated.
LPC I/O bus (Port 80) (LPC1): A 2x5 Pin Header 2.00mm.
It is a proprietary connector for connecting a checkpoint
device to output checkpoints throughout bootblock and
Power-On Self Test (POST) to indicate the task the system
is currently executing.
3 2 1
Pin No. Function Pin No. Function
1 SPI_HD1_N 2 PCH_SPI_CS1_N
3 SPI_CS0 4 V_3P3_SPI
5 SPI_ICH_MISO_R 6 SPI_HOLD0_L
7 NC 8 SPI_ICH_CLK_R
9 Ground 10 SPI_ICH_MOSI_R
10
8
6
4
2 9
7
5
3
1
Pin No. Function PIN NO. DESCRIPTION
1 +5V 2 Ground
3 LSLIN# 4 VEE
5 LAFD# 6 LINIT#
7 FL_PD1 8 FL_PD0
9 FL_PD3 10 FL_PD2
11 FL_PD5 12 FL_PD4
13 FL_PD7 14 FL_PD6
15 LCD- 16 +5V
17 KPA1 18 KPA2
19 KPA3 20 KPA4
21 LCM_RST 22 CTR-GRN
23 CTR-YEW 24 HDDLED_N
Pin No. Function
1-2 SYSTEM RESET
2-3 PCI-E Reset (Default)
3 2 1
Pin No. Function
1 GND
2 TX_P
3 TX_M
4 GND
5 RX_M
6 RX_P
7 GND
Pin No. Function
1 H_VIDALERT_VR
2 H_VIDSOUT_VR
3 H_VIDSCK_VR
4 GND
Pin No. Function
1-2 Hardware reset
2-3 Software reset (default)
Pin No. Function
1-2 Normal (Default)
2-3 Clear CMOS
23 21 19 17 15 13 11 9 7 5 3 1
24 22020 18 16 14 12 10 8 6 4 2
3 2 1
1 2 3 4 5 6 7
1
2
3
4
Pin No. Function Pin No. Function
1 Request To Send
(RTSB#)
2 Data Terminal
Ready (DTRB#)
3 Transmit Data (TXDB) 4 GND
5 GND 6 Receive Data
(RXDB)
7 Data Set Ready
(DSRB #)
8 Clear To Send
(CTSB #)
