Operation
Positioning the paper 1.
To position your paper, first of all please
detach the T-square from the drawing
board. Lay the paper on the board and
slide it under the magnetic clamp bar on
the left side by pressing the control
key down using your left hand and
positioning your paper at right angles
using your right hand (illustration 1).
The paper edge guide will help you with
the alignment. Afterwards, open the
magnetic clamp bar at the lower board
edge and slide the paper underneath
(illustration 2). Use the paper edge guide
to re-check that the paper is straight and
positioned at right angles. Now re-fit the
T-square to the drawing board.
The double guide grooves facilitate
particularly smooth sliding of the bar.
Please ensure that the bar fits correctly
into the grooves.
Sliding the T-square 2.
The T-square can be moved upwards
and downwards easily using the guide
handle (illustration 3). The guide handle
is fitted with an automatic locking
mechanism, permanent free wheel
change (red, grooved) and a “Stop-and-
Go” free wheel change (white).
If the locking device and the free wheel
change are in neutral (not depressed),
the T-square is locked in place
(illustration 4). In order to operate the
“Stop-and-Go” free wheel change and
thus adjust the T-square, depress the
The drawing board is fitted with a
protective film. Please remove this film
before using the device for the first time.
white switch. As soon as you let it go, the
T-square will lock into place
automatically. To adjust the permanent
free wheel change, slide the grooved
red switch to the right (illustration 5).
The T-square can now be moved evenly
without stopping. To lock the T-square
into place, move the switch back to its
original position.
Guide handle with automatic locking me
chanism and free wheel change
Format: Up to DIN A3 (297 x 420 mm)
and uncut formats
Size: 490 x 370 x 38 mm
Weight: 0.9 kg
Guarantee
Dear Customer,
We are delighted that you have decided on
the drawing board. If, contrary to
expectations, you have a technical
problem with your device, please observe
the following points:
The period of guarantee for your device •
is 36 months.
Please be sure to retain the sales receipt •
and the original packaging.
If a problem should arise, please call our •
hotline:
Please be sure to retain!
Hotline International
00800 100 22 100
We are sorry for any inconvenience.
Yours faithfully
Olympia Business Systems
Vertriebs GmbH
