Start-up / Maintenance and Cleaning / Disposal / Information Safety / Start-up
Ensure that a qualified electrician, or a person
trained to carry out electrical installations, per-
forms the electrical installation.
We assume no liability for material damage or
personal injury due to improper handling or
failure to comply with the safety instructions!
Never use the light if any defects have been
identified.
Prior to installation, remove the fuse or switch
off the circuit breaker (0 setting) in the fuse box.
Ensure that the light does not come into contact
with water or other liquids under any circum-
stances.
Prior to installation verify the mains voltage on
site corresponds with the operating voltage
required for the light (230–240 V∼).
Ensure that no cables are damaged when
installing.
Prevent fire and injury
hazards
To prevent burns, ensure that the light is switched
off and has cooled down before touching it.
Do not attach the light to a damp or conductive
substrate.
Do not leave the light or packaging material
lying unattended. Plastic film/bags, plastic parts
etc. can turn into dangerous toys for children.
Do not look directly into the light source (light
bulb, LED etc.).
Safe working
Install the light so that it is protected from moisture,
dirt and excessive heating.
Always be attentive! Always pay attention to
what you are doing and use common sense.
Never use the light if you are having difficulty
concentrating or do not feel well.
Familiarise yourself before use with all instructions
and diagrams in this manual as well as with the
light itself.
This light is not suitable for dimmer or electronic
switches.
The illuminant is not replaceable.
Start-up
Mounting the light
CAUTION! RISK OF ELECTRIC SHOCK!
Disconnect the light from the mains circuit before
installing. To do so, remove the fuse or switch off
the circuit breaker in the fuse box (0 position).
Remove the visible screws 5 on the side of the
connection housing 4 and take off the mount-
ing bracket 1 on the rear (see fig. A).
Use the slotted holes intended for the mounting
bracket
1 to mark the holes for the screws 3 .
Now drill the mounting holes. Ensure that you
do not damage the supply line.
Insert the dowels 2 into the holes. Fasten the
mounting bracket 1 with the provided screws
3 .
Open the junction box.
Feed the power cord through the protective
tube
14 .
Connect the connection cable of the light to
the power cord using the terminal block
13
(see Fig. B).
Be sure to correctly connect the individual con-
ductors of the power cord (external): live con-
ductor, black or brown = symbol L, neutral
conductor, blue = symbol N.
Be sure the protective tube 14 is secured in the
bracket of the junction box.
Close the junction box.
Use the screws 5 to fasten the luminaire to
the mounting bracket 1 .
Now screw the lamp glass (4280-042L) 9 or
(4281-048L) using the screws 12 , the washers
(metal) 11 and the washers (rubber) 10 to the
light.
If necessary, smooth the ropes with the rope
smoother
6 .
Replace the fuse or switch on the circuit
breaker in the fuse box (Position I).
Your light is now ready to use.
