FIG. 12A
FIG.12
FIG. 12
BL55412-14 (The last page) 11 www.themdsports.com
13
14
23
8
34
X 1
X 1
X 1
X 1
X 1
X 2
A13
A14
9
13
14
8
34
A13
36
23
X 1
X 1
FIG. 13
A18
21
FIG.13
23. Insert USB Cable (#A18) into the USB Power.
24. Make sure the Hover Puck is turned to the OFF position. Plug the USB Cable (#A18) into the back of
the Hover Puck (#21). Allow the Hover Puck to charge for 60 minutes.
25. To operate the Hover Puck, just turn on the Switch on the backside of Hover Puck to start. The Hover Puck
will operate for 20-30 minutes when fully charged. See FIG. 13.
22. Fold the Table Tennis Top (#9) , Attach the Rim (#14) to the Table Tennis Top (#9) using one Base (#13) and
two Screws (#A13). And install the Basketball Net (#34) to the Rim (#14). See FIG. 12 and 12A.
YOU ARE NOW READY TO PLAY!
Switch
Charge In
USB Power
21
A18
ON
OFF
MARCHE MADE IN CHINA Fabriqué En Chine
ARRET
