FIG.5
10. Screw the Leg Levelers (#15) into the button of each leg. See FIG. 5.
FIG.6
11. Attach the Lock Pin (#17) to Leg Pedestal (#4) using three Screws (#A11) per Leg Lock Pin. See FIG. 6.
12. Attach the Legs (#6 & #7) to Leg Pedestal (#4) using four Bolts (#A2) and four Washer (#A3) per Leg
Pedestal. See FIG. 6.
FIG. 5
FIG. 6
