TECHNICAL INFORMATION
RPC-2300 Page 33
Serial Port pin out
Pin J1 J4
# Signal Signal
1 N C N C
2 RxD RxD
3 TxD TxD
4 N C N C
5 Gnd Gnd
6 N C N C
7 N C CTS
8 RTS RTS
9 + 5 + 5
10 N C N C
