20
1KHZ – 10KHZ
500.00µA
2.0%+50D UNSPEC’D
0.15mV/µA
5000.0µA 0.15mV/µA
50.000mA 3.3mV/mA
500.00mA 3.3mV/mA
5.0000A
10.000A*
UNSPEC'D UNSPEC'D 45mV/A
*10A continuous, >10A to 15A (to 20A FOR AM-160-A) for 30 second max with
5 minutes cool down interval
DC LOOP CURRENT %4--20MA
4mA = 0% (zero)
20mA = 100% (span)
Resolution: 0.01%
Accuracy: 25D
Crest mode (Instantaneous Peak Hold)
Accuracy: specified accuracy 100 digits for changes > 0.8ms in duration
T1-T2 Dual Temperature (AM-160-A only)
Range Accuracy
-50.0°C TO 1000.0°C 0.3%+1°C
-58.0°F TO 1832.0°F 0.3%+2°F
Thermocouple range & accuracy not included
Hz Line Level Frequency
Function Range Sensitivity
(Sine Rms) Range
500mV 100mV 10HZ ~ 200KHZ
5V 1V 10HZ ~ 200KHZ
50V 10V 10HZ ~ 100KHZ
500V 100V 10HZ ~ 100KHZ
