Xiaomi Mi Vacuum Cleaner Light - Manual (Page 7)

HEPA Filter
Filter Cotton
Dust Compartment
Cyclone Separator
Removing & Installing the Dust Compartment
1. After vacuuming or when the dust
compartment is full, pull out the
extension rod and rotate the dust
compartment in the direction shown in
the figure. When " " is lined up with the
unlock symbol " ", the dust
compartment can be removed from the
vacuum cleaner.
2. Take the HEPA filter out of the dust
compartment as shown in the figure,
then remove the dust from its surface.
Note: Before cleaning or doing maintenance on the vacuum cleaner, turn it off and
unplug it.
Clean the dust compartment regularly to avoid the buildup of dust that could
cause blockage and affect the suction.
To prevent dust from falling on the floor, hold the dust compartment over a trash
can to remove it.
Care & Maintenance
11
HEPA Filter
Dust Compartment
3. Flip the cyclone separator handle over
the trash can to remove the cyclone
separator from the dust compartment, as
shown in the figure. Empty the content in
the dust compartment and clear any dust
from the surface of the cyclone
separator.
4. Place the cyclone separator and HEPA
filter back into the dust compartment
when the cleaning is completed. Align
the unlock symbol " " with " " then
rotate the dust compartment in the
direction shown in the figure until " " is
lined up with the lock symbol " ". Once
you hear a click, the duct compartment
is securely installed onto the vacuum
cleaner.
Installing the Cyclone Separator
Press the cyclone separator straight downwards until it reaches the end of the dust
compartment.
12
Cleaning the Dust Compartment & Filter Assembly
Take the HEPA filter, filter cotton, and
cyclone separator successively out of the
dust compartment. Remove any dust on
their surface, then rinse them with clean
water. Make sure they are thoroughly dry in
a well-ventilated place away from direct
sunlight before use. If necessary, you can
replace the filter with the specified model
of the HEPA filter.
