Handle
Screw
Screw
Tin Plate
Tin Plate
Screw
Motor Cover
Vacuum Cleaner Cover
Button Bracket
Battery Protective Cover
How to Remove the Battery
1. Use a straight screwdriver to
remove the on/off button and the
button bracket, then use a tool to
pray open the vacuum cleaner cover.
Next, use a screwdriver to unscrew
the four screws. Then you can pull
the handle and motor cover to
separate the battery pack.
2. Remove the battery protective
cover, then release the four screws
on the cover with a screwdriver. Use
a scissor to cut off the tin plate
connecting the battery and PCB
board. 3. After removing the up-bracket, the
battery pack can be taken out of from
the down-bracket. Then you can
dispose of the battery in accordance
with local laws and regulations.
15 16
Specifications Precautions for Battery Use
The vacuum cleaner is in standby mode and cannot be used during charging.
The lithium-on battery pack contains substances that are hazardous to the
environment. Before disposing of the vacuum cleaner, please first remove the
battery pack, then discard, or recycle it in accordance with local laws and
regulations of the country or region it is used in.
Note: The vacuum cleaner must be turned off before removing the battery.
The battery should be disposed of in a safe manner.
All products bearing this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be
mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste
equipment to a designated collection point for the recycling of waste
electrical and electronic equipment, appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative consequences to
the environment and human health. Please contact the installer or local authorities for
more information about the location as well as terms and conditions of such collection
points.
Mi Vacuum Cleaner Light
240 Ч 148 Ч 1132 mm Item Dimensions
2500 mAh Battery Nominal Capacity
MJWXCQ03DY
Approx. 0.5 L
Model
Dust Compartment Capacity
Approx. 5 hours Charging Time Approx. 2.3 kg Net Weight
0.5 A Input Current
220 W Operating Power ≤ 79 dB Noise Emission
Input Voltage 26.0 V
21.6 V
71.43%
Battery Service Life (excl. electric floor brush)
45 minutes on standard mode
13 minutes on turbo mode
Power Adapter
84.6% Average Active Efficiency
Efficiency at Low Load (10%)
BLJ15W260050P-VA
100-240 V~ 50/60 Hz 0.5 A
Model
Input
0.10 W No-load Power Consumption Output 26.0 V 0.5 A 13.0 W
Zhongshan Baolijin Electronic Co., Ltd. Manufactured By
Electric Floor Brush
MJWXCQ03DY-DS Model
15 W Operating Power Operating Voltage
